Enhanced Stability: By utilizing high-grade components and precision processing technology, our product significantly reduces the failure rate. Furthermore, the power supply signal dual backup system ensures consistent and reliable operation, supporting uninterrupted 7 * 24-hour functionality.
Superior Refresh Rate: Seamless HD camera shooting with no stripes for a smoother viewing experience.
Low-Light High Gray Performance: Even when brightness is reduced to 20%, our display maintains impeccable grayscale representation. This near-perfect grayscale display at low brightness levels ensures a more vibrant and realistic viewing experience than traditional screens.
Seamless Consistency: A meticulously fine-tuned high-intensity structure achieves seamless stitching across the entire screen, eliminating any visible bright lines. Our point-by-point calibration technology ensures uniform brightness and color across the entire display, enhancing the overall visual impact.
Remarkable Contrast: Featuring high-quality black LEDs and a ripple black sub-black mask, our display offers crisp and vivid images with vibrant colors.
Minimized Reflection: With black matte lights and a corrugated absorber mask, the screen minimizes reflection in bright environments, ensuring clear visibility even in direct sunlight.
Intelligent Brightness Adjustment: Our display automatically adapts to ambient lighting conditions, maintaining optimal visibility without compromising image quality. It maintains nearly perfect grayscale performance across a wide brightness range of 50 to 800 nits.
Ultra-Wide Viewing Angle: Enjoy a viewing angle of 160°/160° on our LED screen, ensuring clear and natural visuals from any angle.
Specifications:
| 1 | Pixel pitch | 1.92mm |
| 2 | Pixel density | 270,421 pixels/sq.m |
| 3 | Pixel configuration | 1R1G1B, SMD1010, 3in1 |
| 4 | LED module size (L*H) | 200*150mm |
| 5 | LED module resolution | 104*78 pixels |
| 6 | LED panel size (L*H*D) | 400*300*80mm |
| 7 | LED panel resolution | 208*156 pixels |
| 8 | LED video wall panel weight | 3.8KG/cabinet |
| 9 | LED video wall panel material | Diecasting aluminum |
| 10 | Brightness | ≥1,200 nits/sq.m |
| 11 | Driving method | 1/32 scan |
| 12 | Viewing angle | ≥145°H /145°V |
| 13 | Best viewing distance | >1.9M |
| 14 | Refresh rate | ≥1,920Hz |
| 15 | Grey scale | ≥4,096 levels |
| 16 | Display colors | >16.7M |
| 17 | Power consumption | Max.:680W/sq.m, Avg.: 272W/sq.m |
| 18 | Input voltage | 110~230V/AC (±10%) |
| 19 | Input power frequency | 50/ 60Hz |
| 20 | IP rating (front/rear) | IP43 |
| 21 | Operating environment | Temperature: -20°C~+50°C, Humidity: 10%~95% |
| 22 | Storage environment | Temperature:-40-50°C, Humidity: 10-90% |
| 23 | Life span (50% brightness) | ≥75,000 hours |
| 24 | Control system | LINSN or other popular control systems |
| 25 | Transmission distance | Multi mode fiber <500m, single mode fiber <30Km, internet cable <100m |
| 26 | Operating system | Windows XP/Win7//8/Vista |
| 27 | Video input/with video processor: Rgblink,Vdwall,Magnimage,etc | VGA,DVI,DHMI,SDI,RGB,CVBS,HD-SDI,etc |
| 28 | Compliant standard | CE/UL/RoHS |
