Outdoor Rental P3.9/P4.8 500X1000 LED display Panel Specification
outdoor COB rental LED display
1. Key Materials and Features
- Driver IC: MBI5124IC
- Power Supply: g-energy
- PCB Thickness: 1.6mm
- Warranty: 2-3 years
2. Inquiry Requirements
- Pixel Pitch: Specify if unknown
- LED screen size: Provide length and width or cabinet quantity
- Usage: Indoor or outdoor? Fixed or rental?
- Installation Location Photos: Recommended for better assessment
3. Product Specification
- Product Name: Outdoor P3.9 Rental LED Display
- Pixel Pitch: 3.9mm
- Pixel Configuration: 1R1G1B/SMD
- Pixel Density: 65,536 dots/m²
- Brightness: 5,000cd/m²
- Module Size: 250mm x 250mm
- Module Resolution: 64 dots x 64 dots
- Module Weight: 500g
- Cabinet Size: (500mm x 500mm) or (500mm x 1000mm)
- Drive IC: ICN 2153
- Drive Mode: 1/16 Scan
- Viewing Angle: 140° (Vertical/Horizontal)
- Grey Scale: 65,536 Degrees
- Lifetime: >100,000 Hours (50% Brightness)
- MTBF: >50,000 Hours
- Operating Voltage: AC110V/220V ± 10%
- Screen Power Consumption: Average: 260w/m²
- Input Power Frequency: 50/60Hz
- Operating Temperature: -30°C to 60°C
- Humidity: 10% – 95%
- Refresh Rate: ≥3,840Hz
- Control Method: Synchronized with Computer Monitor
4. Cabinet Design Details
- Utilizes Hub Card instead of traditional power and flat cables, ensuring stability during shipping and operation.
- Rigid connections are increasingly adopted in high-end rental cabinets, enhancing stability and reliability.
